Pressure Seal Bonnet Globe Valves ASME B16.34/BS 1873
-Materials: A105, LF2, F304,F316, F51,F55, F1, F5, F5A, F9, F11, F22
-Size: 2"-12"
-Class:150LB~2500LB
-Design and manufacture:API 602 / BS 5352
-Face To Face:ANSI B 16.10
-Socket Weld Ends:ANSI B 16.11
-NPT Threaded Ends:ASME B1.20.1
-Butt Welded Ends: ASME B16.25
-Flange Ends: ANSI B16.5
-Test and Inspection:API 598 / BS 5146
Features
-Bolted bonnet design
-OS & Y, Rising Stem
-The Forgings are precision machined for high performance
-Leak proof body-bonnet joint with spiral wound gasket
-Ground finish stem
-Self aligning two-piece gland
-Back seating feature facilitates repacking of the stuffing box on line with the valve in fully open position.
